Accidental contact of elec-trode to metal objects can cause sparks explosion overheating or fire. Projection welding PW is a variation of resistance welding in which current flow is concentrated at the point of contact with a local geometric extension of one or both of the parts being welded.

Projection Welding 101

Welding projection weld nuts and studs.

Projection welding troubleshooting. Therefore if youre wondering what the torque specification should be for your weld nut simply determine the torque capacity of the fastener itself. The flying sparks hot workpiece and hot equipment can cause fires and burns. Projection welding is a resistance welding process of joining two sheets or a sheet and a thick component or a small component like nut to a big body like automotive chasis by making raised portions or projections on one of the components where weld nugget is required to be made.

Expulsion at the weld interface may displace or damage adhesives and sealers. The WeldHelp Resistance Welding Troubleshooting Guide is written for operators and engineers to help diagnose and solve common spot welding defects and issues projection welding and seam welding applications. Advanced Resistance Welding - Surface Conditions -Troubleshooting Service Call 248-701-9328.

Whiskers may prevent the installation of seals or may damage them during installation. The current and the heat generation are localized by the shape of the workpieces either with their. Check and be sure the area is safe before doing any welding.

This method is used for welding nutsbolts to steel plates. Electrodes for resistant spot welding are applied to the projection s provided on one of the base materials. A significant aspect of projection welding is the limited distortion associated with it which is certainly advantageous in terms of geometrical stability.

Suitable projections for projection welding can be formed in steel sheet by embossing and standard designs are set out in BS EN 28167 ISO 8167. If playback doesnt begin shortly try. Consider it an experienced second opinion in a specialized field.

The best document for troubleshooting a seam welder would be. Corrosion is more likely to occur when burrswhiskers are present. Sparks can fly off from the welding arc.

Stainless steels and high alloy nickel base materials are difficult to weld by Projection-welding because of the presence of surface oxides that interfere. Aluminum alloys cannot be joined by Projection-welding because of their tenacious oxides and because these materials soften at low temperature. These installation guides give you many points to troubleshoot on an operating machine.

Elongated projections based on these designs are used particularly when welding curved surfaces to ensure proper set down of the projection and adequate weld. Some colleagues and I have developed what we modestly think is a great tool for identifying welding problems and solutions for resistance spot welding applications. Projection welding has fewer variables that affect the resistance welding process as compared to spot welding.

If this is not. Special considerations are noted below. This article discusses the applications of PW generally categorized as either embossed-projection welding or solid-projection welding.

Projection welding is a resistance welding process for joining metal components or sheets with embossments by directly applying opposing forces with electrodes specially designed to fit the shapes of the workpieces. We make the assumption that the weld on the welded nutstud should be stronger than the fastener itself. This guide includes basic welding knowledge such as welding types and mechanisms and detailed knowledge related to welding automation and troubleshooting.

AWS J122016 GUIDE TO INSTALLATION AND MAINTENANCE of RESISTANCE WELDING MACHINES This document explains the importance of the various aspects of a proper installation. The most important variables of this assembly technique are the quality of the projections and the response of the cylinder as the projection collapses during the welding time. Remove all flammables within 35 ft 107 m of the weld.

However one potential difficulty for the success of projection welding is the cleanliness of the parts or presence of surface films that can inhibit bonding.
